Constant Temperature &Ｈumidity Test Chamber

Constant Temperature &Ｈumidity Test Chamber

Name: Constant Temperature &Ｈumidity Test Chamber
Brand: Universal testing machine,Tensile tester,Climate test Chamber,test Chamber,Thermal Shock Chamber,PW Instruments
SKU: PW-TS series
Availability: InStock
Rating: 5 (1 reviews)

Model: PW-TS series

T/T
FOB
WOOD

Get a free consultation

Description Specification

Product Discription

The temperature and humidity tester is designed for testing the capability of heat-endurance, cold-endurance, dryness-endurance, and humidity-endurance. It is suitable for the industries of electron, electrical equipment, vehicle, metal, chemistry, building materials, luggage, adhesion tape, printing, packaging, etc.

Characteristics

◆ Appearance: high texture appearance, the body adopts circular arc shape, the surface is processed by fog stripe, and adopts plane non-reaction handle, easy to operate, safe and reliable.
◆ Observation window: rectangular multi-layer glass viewing window, which can be used to observe the test products in the test. The window is equipped with anti-sweat electric heater, which can be used for waterproof gas condensation water drops, and high brightness PL glister light to keep the lighting inside the box.
◆ Water supply system: It is equipped with an external water supply system, which is convenient for supplementing the water supply in the humidifying drum and recycling automatically.
◆ Compressor: The compressor circulation system adopts French "Taikang" brand, which can effectively remove lubricating oil between condensing tube and capillary tube, and the whole series adopts environment-friendly cold coal (R404, 507).
◆ Control mode: intelligent PID+SSR/SCR positive and negative two-way synchronous output, including advanced slope control logic.
◆ Controller: with multi-segment program editing and temperature and humidity can do fast (OUICK) or slope (SLOP) control.
◆ System capacity: 150 groups of programs ×1500 sections can be logged in, the number of sections can be divided arbitrarily, and the programs can be freely connected to each other.
◆ Cycle setting: 9999×999 times cycles can be performed, and 5 separate cycles can be cut out.
◆ Time signal: 3 sets of timing control output interfaces, with 10 timing control modes, to facilitate the execution of timing planning for the start/stop of external driver components.
◆ Safety inspection: 15 items of full-function system detection to ensure safe operation of the machine.And can automatically display the time of failure, items and elimination countermeasures.

Model	TS-80-40M	TS-150-40M	TS-225-40M	TS-408-40M	TS-1000-40M
Capacity	80L	150L	225L	408L	1000L
Interior size (cm)WHD	405040	506050	507560	608580	100100100
Exterior size (cm)WHD	9313181	100155 110	100170 120	110180 140	150195 165
Single maximum currently(A)	8A	10A	13A	14A	24A
Rated power(KW)	3.5KW	6KW	7KW	9KW	13KW
Weight(KG)	260	310	320	400	700
Temperature range	-40℃~+150℃
Temperature stability	±0.5℃
Temperature uniformity	±2.0℃
Humidity range	20%~98%RH
Humidity stability	±1.5%
Humidity deviation	≤±5%RH when humidity is less than 75%RH; ≤±3%RH when the humidity is more than 75%RH
Heating up	heat up from -40℃ to +150℃,≤60mins
Cooling down	cool down from +20℃ to -40℃, ≤40mins
Ambient temperature	ambient temperature condition for the chamber working:+5℃~+35℃
Exterior material	1)stainless steel; 2)galvanized steel sheet bake finish
Interior material	SUS304 stainless steel
Insulation technology	outer rigid polyurethane foaminter glass fibre cotton
Refrigeration mode	mechanical vapour compression refrigeration-single stage; cooling mode: air-cooling
Refrigeration compressor	totally enclosed plunger compressor imported from France (low noise/environment protection)
Refrigerant	environment protection R404A(DuPont)
Circulating fan	high temperature induction motorcentrifugal wind wheel
Heater	high reliability stainless steel packaging finned heater/selectable: nickel chrome alloy bare wire heater
